Fidelity Investments works with ElectroRack, Delta Computer, and CPS to present an innovative new rack design to the Open Compute Project.

As the Open Compute Summit ended last week, details emerged of the second one user-originated design of the Open Compute Project: a convertible datacenter rack designed by Fidelity Investments.

Fidelity designed the rack to fulfill the desires of its telco providers within the carrier room, where facilities from different communications suppliers are brought together, while continuing its traditional datacenter operations. The telcos wanted a 23-inch design, but a lot of Fidelity’s datacenters require the EIA-standard 19-inch rack that’s utilized by most enterprises.

These requirements fit with the Open Rack design initially submitted by Facebook. Its version, which serves as a building block of the company’s air-cooled datacenter complex in Prineville, Ore., is a 23-inch rack that permits for spread-out components on a motherboard. Fidelity’s convertible design incorporates dual-sided internal vertical rails that could hold chassis — the frames or trays that hold shelves of servers, disks, or other equipment — designed for 19-inch racks or, if dismantled and reinstalled, 23-inch chassis at the reverse side.

It took Fidelity 75 minutes on its first try and do a conversion. Nuts must be loosened, and the vertical rails should be swiveled around and moved into position before the rack could be reconstructed. But a Fidelity spokesman said that point may be compressed to 45 minutes with a script listing the right kind sequencing of procedures.

It might sound simple, however the design also requires new ways of accommodating cabling, wiring, and tool supplies — a job that had not been addressed during this fragmented and competitive industry. When Brian Obernesser, director of datacenter architecture at Fidelity, took the stage, he cited the 3 rack manufacturers that had worked with Fidelity on building the Open Bridge Rack: ElectroRack, Delta Computer, and CPS.

[Need to learn more in regards to the debate around open-source hardware? See Open Hardware Is Like Linux: True Or False?]

The three companies, which otherwise can be competitors, were open to collaborating on design and contributing back to the community, Obernesser told Summit attendees. a complete of three,476 people registered for the conference in San Jose, Calif.

Traditional racks have wiring and cables popping out of the back. Open Rack’s cable comes down from overhead to feed into front of the rack. Power supplies and gear distribution within the rack are constant variables. While remaining customizable, the Open Bridge Rack distributes power over a shared bus from two power zones, each offering 15 kilowatts.

Fidelity first proposed a bridging rack in January 2013 at an Open Compute hackathon. Five Fidelity team members produced the primary specification of what was then called the “back rack,” which allowed a retrograde configuration. “To be quite honest, it was extremely bulky, heavy, difficult to fabricate, and costly,” Obernesser said. “But this led us to a look for in finding strategic partners within the industry [Delta, CPS, and ElectroRack] with some experience in manufacturing these components.”

He said the team didn’t complete each of the details of the hot design until per week before this year’s summit, which befell Jan. 28-29. Fidelity will use the rack in its carrier rooms, where communications suppliers come together at one point near the datacenter.

Fidelity submitted specifications and 3D schematics of nineteen- and 23-inch racks to the Open Compute Project. “We started with form of a peculiar thing from Facebook, Open Rack,” Matt Corddry, senior manager of engineering at Facebook and chairman of the Open Rack working group, said within the summit’s keynote session.

It’s really evolved far beyond one contribution. We went through a variety of work to fasten in a fine looking robust standard on how the server fits into the rack. And that is provided a type of ecosystem into which various chassis designers, rack designers, and gear shelf designers can build interoperable gear, that is really the Holy Grail of rack design.

The effort has started paying dividends, Corddry said. “I saw a terrific new design from Fidelity and ElecroRack that’s Open Rack-compatible… Among the hallmarks we glance for is Open Rack equipment that emerges that we had nothing to do with. And that is beginning to happen.”
